45621
Dual window flow proportional counter
General Specifications
| MAXIMUM LENGTH (INCH/MM) |
4.48/113.8 |
| MAXIMUM DIAMETER (INCH/MM) |
1.88/47.8 |
| GAS FILLING |
P10 |
| EFFECTIVE LENGTH (INCH/MM) |
2.18/55.4 |
| CATHODE MATERIAL (INTERNAL/EXTERNAL) |
Aluminum |
| EFFECTIVE DIAMETER (INCH/MM) |
0.88/22.4 |
| CONNECTOR |
Pin |
| OPERATING TEMPERATURE RANGE °C |
0 to +50 |
Operating Characteristics
| RECOMMENDED OPERATING VOLTAGE (VOLTS) |
1500 |
| OPERATING VOLTAGE RANGE (VOLTS) |
1400 - 1650 |
| CAPACITANCE (PF) |
3 |
| TYPICAL RESOLUTION (FWHM FE55) |
16 |
EXIT WINDOW SPECIFICATIONS
| MATERIAL |
Mylar |
| AREAL DENSITY (MG/CM²) |
0.8 |
| DIMENSIONS (INCH/MM) |
0.56 x 0.88/14.2 x 22.3 |
ENTRANCE WINDOW SPECIFICATIONS
| MATERIAL |
Mylar |
| AREAL DENSITY (MG/CM²) |
0.8 |
| DIMENSIONS (INCH/MM) |
0.56 x 0.88/14.2 x 22.3 |
