456136

Quadrilateral Be side window proportional counter

General Specifications

MAXIMUM LENGTH (INCH/MM) 3.78/96.1
GAS FILLING Krypton
EFFECTIVE LENGTH (INCH/MM) 1.97/49.9
CATHODE MATERIAL (INTERNAL/EXTERNAL) Aluminum
CONNECTOR Pin
OPERATING TEMPERATURE RANGE °C -40 to +75
MAXIMUM WIDTH (INCH/MM) 1.67/42.5
GAS PRESSURE (TORR) 800
EFFECTIVE WIDTH (INCH/MM) 1.38/35.0
PATH LENGTH (INCH/MM) 1.14/28.98

Window Specifications

MATERIAL Beryllium
THICKNESS (INCH/MM) 0.002/0.05
AREAL DENSITY (MG/CM²) 9.2
DIMENSIONS (INCH/MM) 1.97/49.9 x 0.98/25.0

Electrical Specifications

RECOMMENDED OPERATING VOLTAGE (VOLTS) 1600
OPERATING VOLTAGE RANGE (VOLTS) 1500 - 1750
CAPACITANCE (PF) 3
TYPICAL RESOLUTION (FWHM FE55) 18
