45686

General Specifications

MAXIMUM LENGTH (INCH/MM) 4.56/115.8
MAXIMUM DIAMETER (INCH/MM) 1.0/25.4
GAS FILLING Argon
EFFECTIVE LENGTH (INCH/MM) 2.66/67.5
CATHODE MATERIAL (INTERNAL/EXTERNAL) Stainless Steel
EFFECTIVE DIAMETER (INCH/MM) 0.78/19.8
CONNECTOR Pin
OPERATING TEMPERATURE RANGE °C -40 to +75
GAS PRESSURE (TORR) 800
PATH LENGTH (INCH/MM) 0.78/19.8

Window Specifications

MATERIAL Beryllium
THICKNESS (INCH/MM) 0.002/0.05
AREAL DENSITY (MG/CM²) 9.2
DIMENSIONS (INCH/MM) 0.38 x 1.0/9.5 x 25.4

Electrical Specifications

RECOMMENDED OPERATING VOLTAGE (VOLTS) 1650
OPERATING VOLTAGE RANGE (VOLTS) 1550 - 1800
CAPACITANCE (PF) 3
TYPICAL RESOLUTION (FWHM FE55) 20
