45620

General Specifications

MAXIMUM LENGTH (INCH/MM) 4.68/118.9
MAXIMUM DIAMETER (INCH/MM) 2.0/50.8
GAS FILLING P10
EFFECTIVE LENGTH (INCH/MM) 2.18/55.4
CATHODE MATERIAL (INTERNAL/EXTERNAL) Aluminum
EFFECTIVE DIAMETER (INCH/MM) 0.88/22.4
CONNECTOR Pin
OPERATING TEMPERATURE RANGE °C 0 to +50

Operating Characteristics

RECOMMENDED OPERATING VOLTAGE (VOLTS) 1500
OPERATING VOLTAGE RANGE (VOLTS) 1400 - 1650
CAPACITANCE (PF) 3
TYPICAL RESOLUTION (FWHM FE55) 16

EXIT WINDOW SPECIFICATIONS

MATERIAL Mylar
AREAL DENSITY (MG/CM²) 0.8
DIMENSIONS (INCH/MM) 0.56 x 1.2/14.2 x 30.5

ENTRANCE WINDOW SPECIFICATIONS

MATERIAL Mylar
AREAL DENSITY (MG/CM²) 0.8
DIMENSIONS (INCH/MM) 0.56 x 1.2/14.2 x 30.5
