4515

General Specifications

MAXIMUM LENGTH (INCH/MM) 7.0/177.8
MAXIMUM DIAMETER (INCH/MM) 3.0/76.2
GAS FILLING P10
EFFECTIVE LENGTH (INCH/MM) 4.5/114.3
CATHODE MATERIAL (INTERNAL/EXTERNAL) Aluminum
EFFECTIVE DIAMETER (INCH/MM) 1.88/47.8
CONNECTOR MHV
OPERATING TEMPERATURE RANGE °C 0 to +50
PATH LENGTH (INCH/MM) 1.88/47.8

Window Specifications

MATERIAL Mylar
AREAL DENSITY (MG/CM²) 0.8
DIAMETER (INCH/MM) 1.0/25.4

Electrical Specifications

RECOMMENDED OPERATING VOLTAGE (VOLTS) 1800
OPERATING VOLTAGE RANGE (VOLTS) 1700 - 1950
CAPACITANCE (PF) 3
TYPICAL RESOLUTION (FWHM FE55) 18
