3007

General Specifications

CATHODE MATERIAL (INTERNAL/EXTERNAL) Aluminum
CONNECTOR BNC
FILL GAS Argon, Nitrogen
FILL PRESSURE (TORR) 760
MAXIMUM WIDTH (INCH/MM) 3.0/76.2
MAXIMUM HEIGHT (INCH/MM) 4.06/103.1
MAXIMUM DEPTH (INCH/MM) 0.75/19.1
SENSITIVE DIAMETER (INCH/MM) 2.75/69.9

Neutron Sensitive Material

ENRICHMENT (%) >93
MATERIAL U235
TOTAL QUANTITY (MG) 0.005

Operating Characteristics

RECOMMENDED OPERATING VOLTAGE (VOLTS) 300
OPERATING VOLTAGE RANGE (VOLTS) 50-500
BACKGROUND (COUNTS) 1
NEUTRON SENSITIVITY (COUNTS/1E7 NEUTRONS) 1
